Laminating Machine(YZFM 1000B)

Characteristics: 1. Equipped with high-precision feeding device, accompany with fan below the conveyer belt, and form feeding is smooth and reliable. 2. Electrical motor control uses French Schneider transducer, stable control without fault. 3. The complete machine adopts PLC control systems, which is Schneider brand, has high degree automatization 4. Pressure control is automatic pneumatic control. 5. Heating system adopts oil heating circulatory system. 6. The distance of edge covering for paper (paper length) controlled by variable speed unit. 7. The cutter position is controlled by the structure of photoelectric eye. 8. The paper tear off adopt the structure of photoelectric eye. 9. Tension control adopts electromagnetic powder brakes 10. The machine adopts optical fiber track and will stop automatically when paper out. 11. receiving paper in order and improvework effciency. 1. This machine has passed the CE certification ( laminating machine,lamination machine,laminator) Model YZFM 1000B Max paper size(mm) 1020x760 Min. paper size(mm) 546x393 Max. speed(m/min) 30 m/min Paper range (gsm) 135gsm-450gsm Power(kw) 22kw Overall dimension(mm) 4800x1600x1700mm Net weight (T) 3T
